Shortpass Filters

Product Details

Shortpass Filters Product

Shortpass Filters, also known as Shortpass Edge Filters, are used to transmit wavelengths shorter than the cut-off wavelength of the filter. Shortpass Filters are commonly use in life science applications including fluorescence microscopy or for integration into a variety of instrumentation. Shortpass Filters are typically designed for a 0° Angle of Incidence, whereas Shortpass Dichroic Filters are designed for use at a 45° Angle of Incidence. Shortpass Filters can be used with Longpass Filters to create custom bandpass filters to selectively transmit portions of the spectrum while rejecting all other wavelengths. Shortpass Edge Filters can also be used as hot mirrors to minimize unwanted heat caused by infrared radiation.

Shortpass filter specifications

Product name

Shortpass filter

Cut-off 400-1300nm
Blocking wavelength 300-1650
Optical density OD3; OD4; OD5; OD6
Diameter&Tolerance 0.5-600±0.02mm
Clear Aperture ≥90%
Thickness&Tolerance 0.3-50±0.02mm
Surface flatness 1/10Lambda
Surface quality 10-5
Beveling 45°×0.2mm
Coating  Hard Coated
Please contact us with your specific requirements.
